Place of Origin:
China
Brand Name:
JYY
Certification:
ISO9001
Model Number:
JYY-RD001
| Processing Accuracy | ±0.02mm |
| Product Application | Stainless Steel Bathroom Faucet Grinding |
| Environmental Standards | Complies with Environmental Standards |
| Efficiency Rating | High efficiency |
| Maintenance Requirements | Regular cleaning and inspection |
| Product Type | Welded Stainless Steel Bathroom Faucets |
| Voltage | 220V/380V |
| Robot Type | 6-Axis industrial robot |
| Model | RD-001 |
High-Precision Control
Advanced force-control technology enables precise grinding pressure adjustment, stable material removal, and consistently superior surface finishing quality.
Exceptional Consistency
Eliminates inconsistencies caused by manual operations, delivering uniform, scratch-free, and burn-free finishes with outstanding process repeatability.
High Efficiency
Fully automated continuous operation supports fast product changeovers, optimized production cycles, and increased throughput while reducing labor requirements.
Safe & Environmentally Friendly
Integrated with an efficient dust collection system, the equipment effectively reduces dust emissions, enhances operator safety, and ensures compliance with environmental standards.
Intelligent Digital Management
Real-time monitoring and traceability of process parameters enable seamless MES and ERP integration, facilitating intelligent production management and data-driven manufacturing.
| Model | RD001 |
| Outer Dimensions | L5500 * 3500 * 3300 mm |
| Weight | 1.5T |
| Current | 220V/380V |
| Robot Brand | FANUC |
| Consumables | Abrasive Belt |
| Dust Collection | Dry type |
| Color | Customizable |
| Safety Protection | Safety net / Safety light curtain |
| Function | Robot grinding |
